DNS

DNS is the domain name system. Machines on the internet have numerical addresses called IP addresses, like 35.206.124.218 or 45.79.189.210. In the newer IPv6 system, a typical address looks like 2607:f8b0:4004:80a::200e. These addresses are used by networking software in a similar way to how telephone numbers are used by the phone system. But IP addresses are not easy to remember, especially in IPv6, and organizations often change their IP addresses or have a whole pool of addresses.

To make things easier on humans, we use domain names. Domain names are things like msmary.edu or maps.google.com. DNS is the system that translates between these nice names and the IP addresses required by networking software to properly send around the internet.

Up until the mid 1980s, when the internet was still relatively small, there was a single file called the hosts file that was essentially a big list of which domain names corresponded to which IP addresses. As the internet grew, that file became unmanageably large and would change too frequently, so DNS was created. Instead of using a single file, DNS stores records all over the internet in a hierarchical system.

This hierarchical system is laid out like a tree. At the top of the system is the root level. The first level below it contains what are called top-level domains or TLDs. Below them are individual organizations; each organization can split up their domain into further levels as needed. Below is a very small portion of the overall tree.

The tree can go deeper than this, though most of the domains you'll run into are not that far below the root.

This is important for avoiding phishing attacks. For example, if you're doing your banking with Wells Fargo, you might log on at login.wellsfargo.com. However, if you see a link in an email telling you to click on wellsfargo.login.com or wellsfargo.bheinold.namespace.com, then you should not do so. Notice the domain right next to .com is not wellsfargo in those cases.

Getting a domain name is pretty straightforward. There are various entities called registrars that will do this for you. It's usually just a few clicks and around $10 a year. However, if you want a domain name like pets.com, someone likely has already bought that domain name and will sell it to you for considerably more than $10.

Once you have a domain name, you'll likely want to set up a website at that domain. The quickest way to do this is to find a web hosting company. Again, this is a few clicks and can run anywhere from a few dollars a month to much more depending on what type of site you're running. That hosting site will take care of DNS for you. That involves setting up DNS servers that answer DNS queries about your domain. A cheaper, but more involved approach would be to host the website and the DNS on servers you control, either physical or virtual. This is a good way to learn about how the internet works.

The WHOIS service is used to find out who owns a particular domain name. There is a command line tool for this on Mac/Linux (it's a separate download on Windows), and there are also many websites that run it. The first few lines of a WHOIS lookup for msmary.edu are shown below.

Domain Name: MSMARY.EDU

Registrant:
    Mount St. Mary's University
    Information Technology Department
    16300 Old Emmitsburg Road
    Emmitsburg, MD 21727
    US

The WHOIS protocol is being replaced by RDAP (Registration Data Access Protocol), a newer protocol with some advantages over WHOIS, namely that it returns structured JSON output, runs over HTTPs, and allows for tiered access, where contact information can only be viewed by certain groups, but not others. You can try it out at https://https://client.rdap.org.

Doing DNS lookups yourself

There are a few useful command-line tools for doing DNS lookups. A simple one is nslookup, which is usually available on most major operating systems without having to install anything. Another is dig, which is usually available on Mac and Linux, but not Windows without installing it. On Windows, the PowerShell command Resolve-DnsName behaves somewhat like dig. Here is an example of using nslookup:

> nslookup msmary.edu
Server:  cdns01.comcast.net
Address:  75.75.75.75

Non-authoritative answer:
Name:    msmary.edu
Address:  35.206.124.218

The first two lines of the output give the name and address of the server (called a DNS resolver) that does the lookup for me. These belong to my ISP, which is Comcast Cable. Then comes the answer we are looking for, namely the IP address of msmary.edu. We'll see a little later why it's called “non-authoritative”.

Here is the output of running dig. You'll notice that dig gives a lot more information. There are various options we can use with dig to get even more info.

> ./dig msmary.edu

; <<>> DiG 9.9.11 <<>> msmary.edu
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 59180
;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 512
;; QUESTION SECTION:
;msmary.edu.                    IN      A

;; ANSWER SECTION:
msmary.edu.             3410    IN      A       35.206.124.218

;; Query time: 20 msec
;; SERVER: 75.75.75.75#53(75.75.75.75)
;; WHEN: Sun Aug 16 22:49:07 Eastern Daylight Time 2020
;; MSG SIZE  rcvd: 55

How DNS works

DNS is essentially a distributed database. No one machine in the whole network of DNS servers has all the answers. Each machine is responsible for knowing one or more small portions of the DNS tree, called zones. And there is redundancy built into the system so that even if some servers go down, the system still functions.

There are two categories here: resolvers and name servers. Resolvers ask questions and name servers answer them. A Name servers that is responsible for knowing the answers to a specific zone is said to be authoritative for that zone. In DNS parlance, an authoritative answer is basically first-hand knowledge. Any other answer is non-authoritative, meaning it's second-hand knowledge, sort of like “I heard from this other server that the address you're looking for is 1.2.3.4”.

In the DNS hierarchy, there are root name servers, TLD name servers, and name servers run by organizations with domains. Root name servers have one major responsibility: knowing who the TLD name servers are. Each TLD name server is responsible for the name servers for the individual organizations that use that TLD. For instance, edu name servers know the addresses of Mount St.\ Mary's name servers as well as all other schools with .edu addresses. Finally, each organization's name servers are responsible for the domains belonging to that organization. For instance, the Mount's name servers are responsible for the addresses of inside.msmary.edu, canvas.msmary.edu, etc. Large organizations may break their organization's domain namespace into multiple zones managed by different DNS servers.

Looking back at the tree, servers at each level are responsible for knowing the addresses of the name servers at the level directly below them. In the tree, there is only one root zoon, but that root is actually broken up into 13 separate networks of servers spread throughout the world. Each TLD is also an entire network of servers. This is important for making DNS resilient to servers going down and also so that it can handle trillions of requests a day.

A typical DNS lookup follows a multistep process. Let's say you want the IP address of msmary.edu. Here are the steps:

1. Your computer sends a request to a resolver to do the DNS query. If you're home, the resolver might be running on a server at your ISP. If you're at an organization, that organization may have a resolver on their network. It's also common for people to use open public resolvers, such as those provided by Google or Cloudflare.
2. The resolver contacts a root name server. The root name server identifies an appropriate TLD name server (in this case it's an edu name server).
3. The resolver contacts the TLD name server. That name server identifies the authoritative name servers for the domain (in this it would be Mount St.\ Mary's DNS name servers).
4. The resolver contacts an authoritative name server and gets the address it is looking for. It then sends that back to your computer.

How long will the answers be remembered for? This is determined by something called the TTL (time to live). This is a value set by the administrator of a domain's name servers. For instance, the people that run the Mount's name servers decide what the TTL should be for msmary.edu. The TTL value can run anywhere from a few seconds up to several days. Organizations don't want the TTL to be too short because otherwise you lose the benefits of caching, as entries will expire so often that tons of queries will have to be made. They also don't want it to be too large because if the organization needs to change addresses, people will be using the old, cached address instead of the new one.

While connected to the Mount's network, I ran dig gatorade.com, and got the following:

;; ANSWER SECTION:
gatorade.com.           7199    IN      A       45.60.75.51

The value 7199 is the TTL in seconds, which means the entry is valid for about 2 hours. Anytime in the next two hours someone on the Mount's network asks for the IP address of gatorade.com, the Mount's resolver will return the cached value 45.60.75.51 and not do a full lookup. After those 2 hours are up, if someone asks for gatorade.com's IP address, a new DNS multistep lookup will have to be performed.

Just for effect, after writing the above paragraph, I reran the dig command and got the following output. Note that the TTL is down to 6959, meaning about 4 minutes have elapsed.

;; ANSWER SECTION:
gatorade.com.           6959    IN      A       45.60.75.51

You can actually use the TTL to tell if other people on your network have been to a specific domain recently. If you run dig for that domain and get an unusual TTL, like 6959, it's likely that you're seeing a cached result. The dig command will also tell you how long it took to do the query. Try a few different domains. Ones that are cached will take significantly less time because there doesn't need to be that multistep lookup.

This is important because not all resolvers are honest. Say you are on the Mount's network using their DNS resolver and you ask for the IP address of a competitor, like loyola.edu. The Mount's admins could configure their resolver to always return a bogus IP address instead of the real Loyola address. To get around this, you could use one of the open DNS resolvers mentioned above (assuming that you trust them). There have been many cases in the past of ISPs doing shady things with their resolvers. One of the most famous cases was when the country Turkey blocked address to Twitter by having resolvers in the country return bogus answers for DNS queries for Twitter. People spray-painted 8.8.8.8 on the sides of buildings to tell people how to get around it.

A related topic is the hosts file. This is a file on your computer that has hard-coded domain to IP address mappings. For instance, you can put an entry like msmary.edu 144.126.4.114 into the file. The address 144.126.4.114 is Loyola College's IP address. Usually your OS will check the hosts file before contacting a resolver. So when anyone on your computer tries to go to msmary.edu, they will instead end up at Loyola. The file is located at /etc/hosts on Mac and Linux and at windows/system32/drivers/etc/hosts on Windows.

\paragraph{DNS attacks There's a whole class of attacks called DNS cache poisoning that involve attackers intercepting a resolver's DNS queries and returning bogus answers to them. The resolver then caches the bogus answers, which then affects everyone using the resolver for queries on those domains. It takes some skill to do these on an ordinary network.

Another DNS attack is as follows: The attacker uses their laptop as a Wi-Fi access point. Some laptops allow this, and for others, they can get a cheap USB Wi-Fi device to do this. They also download free DNS server software (a popular one is BIND) that lets them use their laptop as a DNS resolver. They set up shop somewhere in public and wait for people to connect to their Wi-Fi. When people connect, the attacker's access point tells the victim's computer that the resolver to use is the attacker's resolver. When the victim tries to go to something like Gmail, the attacker's DNS will instead give them the IP of a phishing site that looks just like Gmail. The attacker can then get the victim's login credentials.

gatorade.com.           6959    IN      A       45.60.75.51

We see it is broken into five parts. They are the domain name, the TTL, the class, the record type, and the value. Here is what they mean:

• Domain name — The name of the domain that the info was requested for.
• TTL — How long until the record expires from the cache.
• class — It's almost always IN for “internet”.
• type — What type of record this is. There are several types, which are described below.
• value — The actual answer to the question being asked. In the example above, it's the IP address.

Here are some of the more common record types:

• A — Maps a name to an IPv4 address.
• AAAA — Maps a name to an IPv6 address.
• MX — Shows where to find domain's email servers.
• CNAME — Used for aliases. Sometimes the domain name an organization wants the public to use is different from the domain name they want to use internally. As an example, say we run the command dig. Note that this address is what we use for accessing Canvas. Here is what we get back:

  msmary.instructure.com. 269     IN      CNAME   cluster87.instructure.com.


  The company Instructure, who runs Canvas, internally stores Mount St.\ Mary's Canvas stuff at the domain dig CNAME msmary.instructure.com. Presumably, Instructure stores our school's stuff at cluster87, some other school's stuff at cluster88, etc. Mount students don't want to have to remember that our stuff is at cluster87, so they give us the nicer domain cluster87.instructure.com by using a CNAME alias. Moreover, Instructure might in the future move us to somewhere else, like cluster144. By using a CNAME record, all they will have to do is update that record and not have to worry about notifying us that we're now at cluster144.

• PTR — Used for reverse DNS lookups (looking up a domain name based on the IP address).
• SOA — Has administrative info about the DNS zone.
• NS — The names of the zone's authoritative name servers.
• TXT — Originally a catchall for various information that doesn't fit into one of the other types, though it is often now used to hold certain security settings and prove ownership of a domain.
